u Avoidtreesandshrubs.Treebark,woodmoldings,siding,
andfencepostscaneasilybedamagedbythestring.
Cutting line / line feeding
Yourtrimmeruses1.65mmdiameter,Roundnylonline.
Duringuse,thetipsofthenylonlineswillbecomefrayedand
wornandthespecialselffeedingspoolwillautomaticallyfeed
andtrimafreshlengthofline.Cuttinglinewillwearfasterand
requiremorefeedingifthecuttingoredgingisdonealong
sidewalksorotherabrasivesurfacesorheavierweedsare
beingcut.Theadvancedautomaticlinefeedingmechanism
senseswhenmorecuttinglineisneededandfeedsand
trimsthecorrectlengthoflinewheneverit’srequired.Donot
bumpunitongroundinattempttofeedlineorforanyother
purposes.
Clearing jams and tangled line (Figures N, O, P)
Warning!Removethebatteryfromthetrimmerbeforemaking
anyassembly,adjustmentsorchangingaccessories.Such
preventivesafetymeasuresreducetheriskofstartingthe
applianceaccidentally.Fromtimetotime,especiallywhencut-
tingthickorstalkyweeds,thelinefeedinghubmaybecome
cloggedwithsaporothermaterialandthelinewillbecome
jammedasaresult.Toclearthejam,followthestepslisted
below.
u Removethebatteryfromthetrimmer.
u Pressthereleasetabs(22)onthelinespoolcap(23),
asshowninFigureNandremovethecapbypullingit
straightoff.
u Pullthenylonlinespooloutandclearanybrokenlineor
cuttingdebrisfromthespoolarea.
u Placespoolandlineintospoolcapwithline“parked”in
slotsprovidedasshowninFigureO1.
u Insertthelineendthroughtheappropriateholeinthe
spoolhousing.Pullslacklinethroughuntilitpullsoutof
theholdingslotsasshowninFigureO2.
u Pressthespooldowngentlyandrotateituntilyoufeelit
dropintoplaceandthenpushtosnapintoplace.(When
inplace,thespoolwillturnafewdegreesleftandright
freely).
u Takecaretokeepthelinefrombecomingtrappedunder
thespool.
u Alignthespoolcaptabswiththeslotsonthespoolhous-
ing.
u SnapthespoolcapbackonasshowninFigurePby
depressinglugsandpressingintospoolhousing.
Note:Makesurethatcoverisfullypositioned,listenfortwo
audibleclickstoensurebothlugsarecorrectlylocated.Power
theapplianceon.Inafewsecondsorlessyou’llhearthe
nylonlinebeingcutautomaticallytotheproperlength.
Warning!Toavoidappliancedamage,ifthecuttingline
protrudesbeyondthetrimmingblade,cutitoffsothatitjust
reachestheblade.
Note:Otherreplacementparts(guards,spoolcaps,etc.)are
availablethroughBLACK+DECKERservicecenters.Tond
yourlocalservicelocationvisitwww.blackanddecker.com.
Warning!Theuseofanyaccessorynotrecommendedby
BLACK+DECKERforusewiththisappliancecouldbehazard-
ous.
Replacing the spool
u Removebatteryfromappliance.
u Depressthetabs(20)andremovethespoolcap(21)from
thespoolhousing(11)(FigureN).
u Graspemptyspoolwithonehandandspoolhousingwith
otherhandandpullspoolout.
u Iflever(24)(FigureQ)inbaseofhousingbecomes
dislodged,replaceincorrectpositionbeforeinsertingnew
spoolintohousing.
u Removeanydirtandgrassfromthespoolandhousing.
u Unfastentheendofthecuttinglineandguidethelineinto
theeyelet(O2)FigureO.
u Takethenewspoolandpushitontotheboss(25)(Figure
Q)inthehousing.Rotatethespoolslightlyuntilitis
seated.Thelineshouldprotrudeapproximately136mm
fromthehousing.
u Alignthetabsonthespoolcapwiththeslotsinthehous-
ing(FigureP).
u Pushthecapontothehousinguntilitsnapssecurelyinto
place.
Rewinding spool from bulk line
Bulklineisalsoavailableforpurchasefromyourlocalretailer.
Note:Handwoundspoolsfrombulklinearelikelytobecome
tangledmorefrequentlythanBLACK+DECKERfactorywound
spools.
Forbestresults,factorywoundspoolsarerecommended.To
installbulkline,followthestepsbelow:
u Removebatteryfromappliance.
u Removetheemptyspoolfromtheapplianceasdescribed
in“Replacingthespool.”
u Removeanyremainingcuttinglinefromthespool.
u Makeafoldattheendofthecuttinglineatabout19mm
(26).Feedthecuttinglineintooneofthelineanchoring
slots(27)asshowninFigureR.
u Insertthe19mmendofthebulklineintothehole(28)in
thespooladjacenttotheslotasshowninFigureS.Make
surethelineispulledtightagainstthespoolasshownin
FigureS.
u Windthecuttinglineontothespoolinthedirectionofthe
arrowonthespool.Makesuretowindthelineonneatly
andinlayers.Donotcrisscross(FigureT).
u Whenthewoundcuttinglinereachestherecesses(29),
cuttheline(FigureS).
u Fitthespoolontotheapplianceasdescribedin“Replac-
ingthespool”.
Maintenance
YourBLACK+DECKERcorded/cordlessappliance/toolhas
beendesignedtooperateoveralongperiodoftimewitha
minimumofmaintenance.Continuoussatisfactoryopera-
tiondependsuponpropertool/appliancecareandregular
cleaning.
Yourchargerdoesnotrequireanymaintenanceapartfrom
regularcleaning.
Warning!Beforeperforminganymaintenanceoncorded/
cordlesspowertools:
u Switchoffandunplugtheappliance/tool.
u Orswitchoffandremovethebatteryfromtheappliance/
tooliftheappliance/toolhasaseparatebatterypack.
u Orrunthebatterydowncompletelyifitisintegralandthen
switchoff.
