Black+Decker STC1820PC - Troubleshooting and Technical Data; Troubleshooting Common Issues

13
ENGLISH
(Original instructions)
u Unplugthechargerbeforecleaningit.Yourchargerdoes
notrequireanymaintenanceapartfromregularcleaning.
u Regularlycleantheventilationslotsinyourtool/appliance
andchargerusingasoftbrushordrycloth.
u Regularlycleanthemotorhousingusingadampcloth.Do
notuseanyabrasiveorsolvent-basedcleaner.
u Regularlycleanthecuttinglineandspoolusingasoft
brushordrycloth.
u Regularlyuseabluntscrapertoremovegrassanddirt
fromtheunderneathoftheguard.
Troubleshooting
Problem
Solution
Appliance runs slowly. Removebatteryfromtrimmer.
Checkthatthespoolhousingcanrotate
freely.Carefullycleanitifnecessary.
Checkthatthecuttinglinedoesnotpro-
trudemorethanapproximately122mm
fromthespool.Ifitdoes,cutitoffsothat
itjustreachesthelinetrimmingblade
Automatic line feed does not
feed line.
Morelineisfedwhenthelineshortens
toapproximately76mm.Todetermineif
thelineisnotfeeding,letlinewearpast
thispoint.
Keepthetabsdepressedandremovethe
spoolcapwiththespoolfromthespool
housinginthetrimmerhead.
Ensurethatthelineisnotcrisscrossed
onthespoolasdetailedin(Fig.T).Ifit
isunwindthecuttinglineandrewind
itneatly.
Inspecttracksatthebottomofspoolfor
damage.Ifdamaged,replacespool.
Pullthecuttinglineuntilitprotrudes
approximately122mmfromthespool.If
insufcientcuttinglineisleftonthespool,
installanewspoolofcuttingline.
Alignthetabsonthespoolcapwiththe
cutoutsinthehousing.
Pushthespoolcapontothehousinguntil
itsnapssecurelyintoplace.
Ifthecuttinglineprotrudesbeyondthe
trimmingblade,cutitoffsothatitjust
reachestheblade.Iftheautomaticline
feedstilldoesnotworkorthespoolis
jammed,trythefollowingsuggestions:
Carefullycleanthespoolandhousing.
Makesureyouareusingcorrectlinesize
anddiameter(2.00mm)-smallerand
largerlinesizeswillaffectthefunctional-
ityoftheautofeedsystem.
Removethespoolandcheckifthelever
inthespoolhousingcanmovefreely.
Removethespoolandunwindthecutting
line,thenwinditonneatlyagain.Replace
thespoolintothehousing.
Overfeeding Ensureyouarecuttingwiththetipofthe
line177mmfromthespool.Usetheedge
guideifneededtoensureproperspace
ismaintained.
Ensureyouarenotexceedinga10ºan-
gleasshownin(Fig.M).Avoidcontactof
thelinewithhardsurfacessuchasbrick,
concrete,woodetc.Thiswillprevent
excessivewearand/oroverfeedofline.
Cutwiththetipoftheline
Line unravels when cap or
spool is removed
Makesuretoparkthelinesinholding
slots(FigureR)beforeremoving.
Protecting the environment
Z
Separatecollection.Productsandbatteries
markedwiththissymbolmustnotbedisposedof
withnormalhouseholdwaste.
Productsandbatteriescontainmaterialsthatcanberecov-
eredorrecycled,reducingdemandforrawmaterials.Please
recycleelectricalproductsandbatteriesaccordingtolocal
provisions.Furtherinformationisavailableat
www.2helpU.com
Technical data
STC1820PC
H2
Input Voltage
V
DC
18V
No-Load Speed
min
-1
5500/7400
Weight
kg
2.55Kg
Battery
BL2018
Voltage
V
DC
18V
Capacity
Ah
2.0
Type
Li-Ion
Charger
905902**(typ.1)
Input Voltage
V
DC
230
Output Voltage
V
DC
18
Current
mA
Input:
400
Hand/armweightedvibrationvalueaccordingto
EN50636-2-91:
=<2,5m/s
2
,uncertainty(K)=1.5m/s
2
.
L
PA
(soundpressure)79dB(A)
uncertainty(K)=3dB(A)
