Blade mSR X - Exploded View and Parts Listings; Optional Parts

11
EN
Exploded View and Parts Listings
Part # Description
A BLH3218 Complete Red-White Canopy w/
Vertical Fin: mSR X
B BLH3203 Coreless Main Motor w/ Pinion:
mSR X
C BLH3506 Main Gear: mSR/X, mCP X
D BLH3201 4-in-1 Control Unit, RX/Gyro/
Servos/ESCs: mSR X
E BLH3208 Servo Push Rods w/Ball Link (2):
mSR X
F BLH3205 Main Frame with Hardware: mSR X
G BLH3515,
EFLH2215
OuterShaftBearing3x6x2mm(2):
mCX/2/mSR/X,FHX,mSR X
H BLH3215,
EFLH3015
Rotor Head Linkages (4): mSR/X
I BLH3209 Complete Precision Swashplate:
mSR X
J BLH3214 Main Blade Grips w/Hardware (2):
mSR X
K BLH3212 Main Rotor Hub w/Hardware:
mSR X
L BLH3207 Carbon Fiber Main Shaft w/Collar &
Hardware: mSR X
M BLH3217,
EFLH3017
Tail Rotor: mSR/X
Part # Description
N BLH3202 Tail Boom Assembly with Motor/
Rotor/Mount: mSR X
O BLH3204 Landing Skid and Battery Mount:
mSR X
P BLH3213,
EFLH3013
Feathering Spindle w/O-Rings and
Bushings: mSR/X
Q BLH3521,
EFLH3021
Canopy MntngGrommet(8):m CX
2/T, mSR/X,FHX,MH-35, mCP X
R BLH3216 Main Rotor Blades w/ Hardware
(2): mSR X
S BLH
3220RW
Vertical Fin, Red-White: mSR X
T SPM6836 Servo Mechanics 2.3 g
U EFLB
1501S25 
150mAh 1S 3.7V 25C Li-Po Battery
BLH3222 Hardware Set: mSR X
EFLH
1064B
Blade MLP4DSM 4-Channel Trans-
mitter, 2.4GHz: mCX2, 120SR, mSR
X (Mode 2)
EFLH
10641
MLP4DSM 4-Channel Transmitter,
2.4GHz Mode 1: mCX, mSR/X
EFLC1000 1-Cell 3.7V 0.3A DC Li-Po Charger
Part # Description
BLH3218R Complete Red Canopy w/ Vertical Fin:
mSR X
BLH3216GL Main Rotor Blades w/Hardware, Glow
in Dark (2): mSR X
BLH3220GL Vertical Fin, Glow in Dark: mSR/X
BLH3217GL Tail Rotor, Glow in Dark: mSR/X
BLH3204GL Landing Skid and Battery Mount,
Glow in Dark: mSR X
BLH3205GL Main Frame w/Hardware, Glow in
Dark: mSR X
BLH3216OR Main Rotor Blades, Orange (2): mSR X
BLH3217OR Tail Rotor, Orange: mSR/X
BLH3216RE Main Rotor Blades, Red (2): mSR X
BLH3217RE Tail Rotor, Red: mSR/X
EFLC1005 AC to 6VDC 1.5-Amp Power Supply
(US)
Part # Description
EFLC
1005UK
AC to 6VDC 1.5-Amp Power Supply
(UK)
EFLC
1005EU
AC to 6VDC 1.5-Amp Power Supply
(EU)
EFLC
1005AU
AC to 6VDC 1.5-Amp Power Supply
(AU)
EFLC1006 Celectra 1S 3.7 Variable Rate DC
Li-Po Charger
EFLC1004 Celectra 4 port charger
EFLC
1004AC
Celectra 4-Port Charger with AC
Adapter Combo (US)
PKZ3052 Battery connector w/ wire
EFLH3023 mSR Training Gear
BLH3235 Complete EC120B Body Set: mSR X
DX5e DSMX 5-Channel Transmitter
Only
Optional Parts
