BLADEZ BF-390E Elliptical
SECTION 2
ASSEMBLY INSTRUCTIONS
ITEM # DESCRIPTION QTY
1
Computer Assembly
1
10
Upright
1
14
Frame
1
64
Stabilizer
2
65
Moving Wheel
2
66
Foot Pad
2
94
Pedal Assembly (L)
1
95
Pedal Assembly (R)
1
98A
Left Handrail
1
98B
Right Handrail
1
101
Computer
1
102
Pedal
2
103
End cap
2
104
Cover (L)
2
105
Cover (R)
2
106
Bottle
1
107
Bottle Holder
1
108
Necklace Bracket
1
109
Adaptor
1
126
Lubricant
1
