BLADEZ Evora - Detailed Parts List

20
PARTS LIST
Part # Description Quantity
33
Bushing
1
34
Bearing
2
35
Wheel sprocket
1
36
Chainwheel fixing nut
2
37
Axle
1
38
Hex head nut
6
39
Knob M10
4
40
Rear Stabilizer
1
41
Carriage bolt
4
42
Flat washer
1
43
Cap nut
6
44
Self-tapping screw
6
45
Left chain cover
1
46
Self-tapping screw
2
47
Big chain wheel
1
48
Chain
1SET
49
Right chain cover back
1
50
Right chain cover front
1SET
51
Wheel
2
52
Flat washer
4
53
Hex head screw
2
54
Nut
2
55
Front stabilizer
1
56
Main frame
1
57
Brake pad bracket
1
58
Brake pad
1
59
Plastic wire holder
1
60
Sensor line
1
61
Adjustable handlebar post
1
62
Curved washer
2
63
Spring washer
2
64
Combination wrench
1
Part # Description Quantity
1 Computer 1
2 End cap for handlebar 2
3 Handlebar foam 2
4 Handlebar 1
5 Carriage bolt 2
6 Saddle 1
7 Seat support 1
8 Plastic cap 3
9 Plastic bushing 4
10 Plastic cap for brake pole 1
11 Round nut 1
12 Hex head nut 1
13 Brake pole 1
14 Spring 1
15 Water bottle holder 1
16
Adjustable T-shaped
seatpost
1
17 T-shaped knob 2
18 Plastic sprocket 1
19 Self-tapping screw 11
20L Pedal (Left) 1
20R Pedal (Right) 1
21L Crank (Left) 1
21R Crank (Right) 1
22 Round cap 2
23 Hex head bolt 2
24 Boot bearing 1
25 Lock ring 1
26 Wave washer 1
27 Flat washer 1
28 Bearing 2
29 Cap nut 2
30 Adjust bolts 2
31 Hex head nut 2
32 Flywheel 1
