Operating Instructions 1-7D
Spare parts
10.1 Spare parts 1-7D
Blast wheel unit
Item Part no. Description Qty.
1 001628 Tune-up kit 1
2 959635 Wheel hub 1
001626 Cage retaining plate 1
3 959639 Wheel nut 1
970012 Control cage clamp 2
4 969580 Left liner 1
5 969581 Right liner 1
6 959676 Top liner 1
B21044 Top liner (casted) 1
2
1
3
4
5
6
Fig. 10.1
