1-7D Operating Instructions
Spare parts
Blast head
Item Part no. Description Qty.
1 001623 Front & rear brush 2
2 001624 Side brush 2
3 969763 Front magnet 1
4 969780 Side magnet 2
Fig. 10.2
Drive unit
Item Part no. Description Qty.
1 971518 Swivel castor 2
2 960682 Wheel 2
3 001627 Wheel support 1
4 B20052 Front wheel bar 1
Fig. 10.3
3
