14
External audio/video sources
AV inputs
This device features two external AV inputs for audio and
video playback. The 1st AV-IN input is located under the
cover at the front of the device below the rotary knob
and the second at the rear of the radio.
Danger!
Increased risk of injury from connector.
In case of an accident, the protruding connector in the
front AV-IN socket may cause injuries. The use of straight
plugs or adapters leads to an increased risk of injury.
Start the AV-IN mode with the button AV-IN 1 /
AV-IN 2 .
The display shows the audio or video playback of the
selected AV source.
Rear Camera input
This device features a video input at the rear of the device
for connecting a camera that is available as an option. If
a rear camera is connected, the image is displayed on the
screen, when the rear gear is engaged.
External monitor
This device features an output for connecting an external
monitor for passengers in the rear (see Connection
diagram at the end of these instructions).
Select the desired source via the main menu and
start movie playback.
The movie is displayed on the monitor of the device.
Turn the Video out on with icon "Rear Zone".
The lm is also displayed on the external monitor.
DAB mode(only for models with DAB)
The function allows you to receive the DAB stations.
Starting DAB mode
In the main menu, press on [ DAB ].
[ ] Select DAB band from DAB1, 2 and 3.
[
] Short press: Manual tune backward.
Long press: Auto tune backward.
[
] Select search mode.
[
] Short press: Manual tune forward.
Long press: Auto tune forward.
[
] Store stations automatically.
[
] Show additional operating options.
[ ] Hide additional operating options.
[
] Turn on/o L-Band.
[
] Search all service available.
[ PTY ] Search service by Programme Type.
[ TA ] Turn on/o Trac Announcement.
[ DAB-FM ] Turn on/o DAB-FM.
[
] Display equalizer.
