18
CLEAN/REPLACE THE SIDE BRUSH
1 Turn over the machine and pull the side brush out and upwards
2 Remove hair and dirt and reassemble the side brush.
3 Make the left-side brush (L) and the right-side brush (R) correspond to L
and R on the bottom casting, press L and R to reinstall them.
CLEAN THE SENSORS
Clean the sensors with a soft, dry mop, including:
1 Three anti-dropping sensors at the bottom of the robot.
2 Electric shock protector and the pins to connect with the charging
station at the bottom of the robot (please cut the power o during
cleaning)
3 Signal transmission area of charging/auto station.
MAINTENANCE
Anti-drop sensor
Charging contact points
TOF sensor
LDS Laser ranging
sensor
Anti-colision sensor
for radar
Anti-colision sensor
Infrared recharging
sensor
