Page 11
G70™ Moving Head Spot - Rev. A (c) 2014 Blizzard Lighting, LLC
Clamp Mounting
Thisxtureprovidesamountingbracketassemblythatsecuresthe
bottom of the base, the “Omega Brackets,” and the safety cable
riggingpointtogether.Whenmountingthisxturetotruss,besureto
secure an appropriately rated clamp to the omega bracket using an
M10screwttedthroughthecenterholeofthe“omegabracket”.
Securing the Fixture
Regardlessoftheriggingoptionyouchooseforyourxturesalwaysbe
suretosecureyourxturewithasafetycable.Besuretoonlyusethe
designated rigging point found on the underside of the base assembly
for the safety cable. Never secure a safety cable to a carrying handle.
1.) Clamp
2.) Omega Bracket
3.) ¼ Turn Quick Lock Fasteners
2
3
1
