Blizzard Lighting G70 - DMX Channel Values In-Depth

Page 14
G70™ Moving Head Spot - Rev. A (c) 2014 Blizzard Lighting, LLC
DMX Channel Values In-Depth
Reduced
Mode
Standard
Mode
Channel
Value
What it does
1 1 000 <-> 255 Pan
... 2 000 <-> 255 Pan Fine (16-Bit Pan)
2 3 000 <-> 255 Tilt
... 4 000 <-> 255 Tilt Fine (16-Bit Tilt)
... 5 000 <-> 255 Movement Speed (fast <--> slow)
3 6
000 <-> 009
010 <-> 019
020 <-> 029
030 <-> 039
040 <-> 049
050 <-> 059
060 <-> 069
070 <-> 079
080 <-> 099
100 <-> 119
120 <-> 139
140 <-> 159
160 <-> 179
180 <-> 199
200 <-> 219
220 <-> 255
Color Wheel
Open / White
Magenta
Orange
Green
Blue
Red
Yellow
UV
UV <--> Yellow
Yellow <--> Red
Red <--> Blue
Blue <--> Green
Green <--> Orange
Orange <--> Magenta
Magenta <--> White
Rainbow Effect (slow <--> fast)
4 7
000 <-> 010
011 <-> 020
021 <-> 030
031 <-> 040
041 <-> 050
051 <-> 060
061 <-> 070
071 <-> 080
081 <-> 095
096 <-> 110
111 <-> 125
126 <-> 140
141 <-> 155
156 <-> 170
171 <-> 185
186 <-> 255
Gobo Wheel #1
No Gobo
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo 1 Shake
Gobo 2 Shake
Gobo 3 Shake
Gobo 4 Shake
Gobo 5 Shake
Gobo 6 Shake
Gobo 7 Shake
Flow Effect (slow <--> fast)
5 8
000 <-> 010
011 <-> 020
021 <-> 030
031 <-> 040
041 <-> 050
051 <-> 060
061 <-> 070
071 <-> 085
086 <-> 100
101 <-> 115
116 <-> 130
131 <-> 145
146 <-> 160
161 <-> 255
Gobo Wheel #2
No Gobo
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 1 Shake
Gobo 2 Shake
Gobo 3 Shake
Gobo 4 Shake
Gobo 5 Shake
Gobo 6 Shake
Flow Effect (slow <--> fast)
6 9
000 <-> 127
128 <-> 189
190 <-> 193
194 <-> 255
Gobo Wheel #2 Rotation
Gobo Indexing
Counter-Clockwise Rotation (fast <-> slow)
Rotation Stop
Clockwise Rotation (slow <-> fast)
7 10
000 <-> 005
006 <-> 009
010 <-> 127
128 <-> 137
138 <-> 255
Prism & Prism Rotation
No Function
Prism Effect
Clockwise Rotation (slow <-> fast)
Stop
CCW Rotation (slow <-> fast)
