Blizzard Lighting G70 - The G70 Pin-Up Picture

Page 6
G70™ Moving Head Spot - Rev. A (c) 2014 Blizzard Lighting, LLC
Figure 1: The G70™ Pin-Up Picture
Lens
Menu
Buttons
LCD Readout
Figure 2: The Rear Connections
DMX OutPower Switch
Power In
Power Out
Head/Arms
Carry Handle
DMX InFuse Cover
