Page 13
SkyBox™ EXA Manual Rev. A © 2014 Blizzard Lighting, LLC
Control Panel Menu Structure
Addr 001 - 512 To choose the DMX address
CHnd 11CH 11 channel DMX mode
8CH 8 channel DMX mode
7CH 7 channel DMX mode
6CH 6 channel DMX mode
AUTO 00 - 63 Static Colors (0-62) & Auto Mode (63)
SPEED 00 - 15 Built-in Program Speed (fast <--> slow)
FADE 00 - 15 Fade Speed (fast <--> slow)
STROBE 00 - 15 Strobe speed (slow <--> fast)
RED 000 - 512 Red dimmer (0% <--> 100%)
GREEN 000 - 512 Green dimmer (0% <--> 100%)
BLUE 000 - 512 Blue dimmer (0% <--> 100%)
AMBER 000 - 512 Amber dimmer (0% <--> 100%)
WHITE 000 - 512 White dimmer (0% <--> 100%)
UV 000 - 512 UV dimmer (0% <--> 100%)
SOUND <ENTER> Sound active mode
DIMMER 0 - 4 Dimming mode (0-4)
RF-ID 1 - 7 Selects wireless channel group (1-7)
IR MODE <ENTER> Set to use IR remote control (sold separately)
OUT MOD <ENTER> Power output mode: H=100%, M=75%, S=50%
