Page 6
SkyBox™ EXA Manual Rev. A © 2014 Blizzard Lighting, LLC
2. MEET THE SKYBOX™ EXA LED PAR
CONTROL FEATURES
• RGBAW+UV color mixing via 7x 15W 6-in-1 LEDs
• 2.4Ghz built-in wireless DMX receiver
• 512 auto-assigning frequencies in 7 groups
• Ultra Long-life intelion™ lithium-ion battery system
• Variable electronic dimming & strobe
• Built-in color & chase macros via DMX
• Built-in automated programs via master/slave
• Built-in sound active programs
• RGBAW+UV color mixing ability in standalone mode
• RGBAW+UV (6-Ch), RGBAW+UV/Strobe (7-Ch), RGBAW+UV/Dimmer/Strobe
(7-Ch), & Extended w/32-bit Dimmer (11-Ch) DMX Proles
ADDITIONAL FEATURES
• Rugged and well-built (It hits the gym regularly)
• Super-quiet variable-speed internal Fan Cooling
• Dual mounting brackets for positioning exibility
• Flicker-free constant-current 400hz LED driver
• 3-pin male input and 3-pin female output
• PowerCon™ compatible AC power In/Out connectors
DMX Quick Reference - 11/8 Channel Modes
Channel 11-Channel 8-Channel
1 Dimmer Dimmer
2 Red Intensity Red Intensity
3 Green Intensity Green Intensity
4 Blue Intensity Blue Intensity
5 Amber Intensity Amber Intensity
6 White Intensity White Intensity
7 UV Intensity UV Intensity
8 Strobe Strobe
9 Static Colors + Auto Run ---
10 Built-in Programs ---
11 32-Bit Dimmer ---
DMX Quick Reference - 7/6 Channel Modes
Channel 7-Channel 6-Channel
1 Red Intensity Red Intensity
2 Green Intensity Green Intensity
3 Blue Intensity Blue Intensity
4 Amber Intensity Amber Intensity
5 White Intensity White Intensity
6 UV Intensity UV Intensity
7 Strobe ---
