Page 22
SkyBox™ EXA Manual Rev. A © 2014 Blizzard Lighting, LLC
6.5in (165mm)
7.84in (199mm)
6.5in (165mm)
1.2in
(28.5mm)
2.6in (65mm)
3.9in (98.15mm)
5.12in (130mm)
Dimensional Drawings
