Blizzard Lighting SkyBox EXA - The Skybox EXA Pin-Up Picture

Page 7
SkyBox™ EXA Manual Rev. A © 2014 Blizzard Lighting, LLC
Figure 1: The SkyBox™ EXA Pin-Up Picture
Figure 2: The Rear Connections
AC Power Out
DMX
In
DMX
Out
Menu ButtonsAC Power In
LED Display
High Power 15w 6-in-1
RGBAW+UV LEDs
Heavy-Duty Steel
Enclosure
Dual
Mounting
Yokes
Antenna
Power Switch
RF-ID Indicator Charge Status LED
Locking
Adjustment
Knobs
