ASSEMBLY
OM 0277-A 13
Figure 6
Removing the Snowblower from Tractor (Figure 6)
1. Set snowblower completely on the ground to
release all pressure from the three-point. Set
parking brake and turn engine off.
2. Detach upper link by removing linchpin and
pin (items 4).
3. Disconnect driveline from tractor P.T.O. shaft
and set driveline on support chain.
4. Carefully detach lower links (items 1) by
removing linchpins (items 2) and loosen anti-
sway turnbuckles.
IMPORTANT
: To avoid damage to the
snowblower, retorque all bolts after the first
10 hours of operation.
