PARTS
OM 0277-A 23
FRAME AND RELATED PARTS – BLIZZARD B54 & B64
#
P IÈCE
R
ÉF . D ESCRIPTION
Q
TÉ B
5
4B
6
4
1 Housin
g
1 --- ---
2 Chute ass'
y
1 664793 664793
3 N
y
lon rin
g
1 659151 659151
4 Bolt hex. 1/4" NC x 3/4" 8 O/L O/L
5 Retainin
g
p
late 4 659146 659146
6 Lockwasher 1/4" dia. hole 8 O/L O/L
7 Nut hex. 1/4" NC 8 O/L O/L
8
Cotter
p
in
∅
1/4" x 2"
2O/L O/L
9 Bearin
g
1 1/4" hole 2 4300001 4300001
10 Bolt hex. 1/2"NC x 1 1/2" 8 O/L O/L
11 Lockwasher 1/2" 12 O/L O/L
12 Nut hex. 1/2" NC 12 O/L O/L
13 Au
g
er 1 666259 666269
14 Fan 1 664400 664400
15 Ke
y
3/8" x 3/8" x 2 3/4" l
g
1 654174 654174
16 Bolt hex. 3/8"NC x 1 1/2" 5 O/L O
/
L
17 Lockwasher 3/8" dia. hole 5 O/L O/L
18 Flat washer 7/16" dia. hole 1 O/L O/L
19 Idler bushin
g
1 666264 666264
20 Idler 1 654010 654010
21 Flat washer 11/16" dia. hole 2 O/L O/L
22 Bolt hex. 5/8"NC x 4 1/2" 1 O/L O/L
23 Idler bushin
g
1 666263 666263
24 Chain #60 x 72 links
,
incl. connect. link 1 659143 659143
25 Fan washer 1 661554 661554
26 Ad
j
ustment tube 1 654076 654076
27 Ad
j
ustment rod 1 654074 654074
28 Round wire lock
p
in 1/4" 1 1900006 1900006
29 Driveline series 40 1 4700042 4700042
30 Hitch
p
in Cat.1 2 654196 654196
31 Bearin
g
1 1/8" hole with lockin
g
collar 1 4300040 4300040
32 Lockwasher 5/8" 1 O/L O/L
33 Nut hex. 5/8"NC 1 O/L O/L
34 Connectin
g
link #60 1 654839 654839
35 Drivin
g
shaft 1 666256 666268
36 Shear
p
late 1 666257 666257
37 Bolt hex. 5/16"NC x 1 3/4"
g
r.5
,
incl. nut 1 665547 665547
38 Gearbo
x
1 663485 663485
39 Nut hex. 3/8"NC 8 O/L O/L
40 Bolt hex. 3/8"NC x 5" 4 O/L O/L
41 Linch
p
in 7/16" PTD 2 O/L O/L
42 Left ad
j
ustable skid shoe 1 666254 666254
43 Ri
g
ht ad
j
ustable skid shoe 1 666255 666255
44 Carria
g
e bolt 1/2" NC x 1" l
g
4O/L O/L
45 Carria
g
e bolt 3/8" x 3/4" l
g
3 O/L O/L
46 Serrated flan
g
e nut 3/8" NC 3 O/L O/L
47 S
p
rocket #60A32 1 654167 654167
48 Self-lubricatin
g
bushin
g
1 4300056 4300056
49 Flan
g
e with
g
rease slot 1 4300014 4300014
50 Flan
g
e with ti
p
and
g
rease fittin
g
1 4300015 4300015
51 S
p
acer 1 667015 667015
