54
Just Power On
MPPT Quantity 1/1 /
AC Adapter Charging
(On PV input port)
500W MAX /
7-8A /
Car Charging
11.5-14.5V
Set DC input source on
screen： Others
12V Lead-acid Battery:
11.5V ± 0.2V；24V Lead-
acid Battery: 23V±0.2V
23-29V
8A
Note：PV Input, Car Charging, and additional Adapter shares the same
Aviation Port.
AC Charging Adapter
Input Voltage 100-240VAC /
Voltage Range 58.8V /
Max. Charging Power 500W /
Note:
a: AC200MAX can be automatically activated (turn the unit ON without
pressing the power button from POWER OFF) via solar power. Please
unplug the DC input cable if you want to disable the auto-activation.
b: AC200MAX cannot be activated via the adapter.
c: Simultaneous charging&discharging supported.
BLUETTI APP(Bluetooth)
Firmware Update 5m/16.4ft /
Wireless Connect 10m/32.8ft /
17. TROUBLESHOOTING
Error Code Description
001 PV Over Voltage
004 DC Output Short Circuit
005 Adapter Over Voltage
006 Adapter Low Voltage
007 Adapter Relay Error
008 Adapter Over Current
