18
(P150D Battery Expansion Cable)
a: Enable/disable the battery expansion function.
b: Lock/unlock the connection.
Capacity Expansion
Connect the AC500 power station with B300S via the P150D battery expansion cable.
Note: Press either the power button on AC500 or B300S to turn on the AC500 + B300S combo.
When AC500 isconnected to power source, the AC500 + B300S combo turns on automatically.
If there’s only one B300S connected, the combo delivers a maximum output of 4500W.
To get 5000W AC output, please connect at least one expansion battery to each expansion port.
a
b
①
Barb down
Lock ②
①
Barb down
Lock ②
