Set the ‘PV’ as DC1/DC2 input source to enable AC/Generator + PV Charging.
Set the ‘Others’ as DC1/DC2 input source to enable AC/Generator + Adapter/Car/Lead-acid Battery
Charging.
Turn on the ‘PV Parallel Enable’ to enable excessive PV charging(＞1500W, ＜150V).
6144Wh* × DoD × η ÷ (load power) = charging time (estimated)
* Take the AC500+2*B300S combo as an example.
Note: DoD refers to the Depth of Discharge, η is the local inverter efficiency. DoD=95%, η=90%.
DoD may vary depending on ambient-operating temperature and discharge rate.
Load power and charging time are measured in Watt and Hour.
Dual Charging
Discharging
17
Wall Outlet
Solar Panel(s) Car
AC Adapter Lead-acid Battery
Smartphone
285-292 Times
18Wh
Fridge
3-4 Days
700W(24h)
Laptop
110-116 Times
45Wh
Microwave Oven
4-5hrs
1000W
Washing Machine
5.2/10.5hrs
500/1000W
Space Heater
2.5-3.5hrs
1500W
Air Conditioner
6-7hrs
8000Btu
Electric Vehicle(16A)
11-15 Miles
1800W
