Bluetti EP500Pro - AC Input (1 st Charging Port: CP1)

Charging via wall outlet
Charging via Sub Panel
10.1.1 Charging Method 1: AC charging
Connect the EP500Pro to a wall outlet via the AC charging cable. The charging auto-
matically stops when the EP500Pro system reaches 100% capacity.
The maximum charging power allowed is up to 3000W.
10.1 AC Input (1
st
Charging Port: CP1)
Pin1Pin2Pin3
Pin1:L
Pin2:N
Pin3:PE
31
JUST POWER ON
