Bluetti EP500Pro - DC Input (2 nd Charging Port: CP2)

10.1.2 Charging Method 2: Generator Charging (Gasoline/Propane/Diesel)
•
Connect the EP500Pro to a generator via the generator charging cable . The
charging automatically stops when the EP500Pro system reaches 100% capacity.
•
Note: It is recommended to use a generator with pure sine wave output, such as
inverter generator.
Please make sure your generator meets the following:
Voltage: 207-253VAC
Frequency: 47Hz-53Hz/57Hz-63Hz*
* If the AC input frequency of EP500Pro is set to 50Hz, use a generator with a fre-
quency of 47Hz-53Hz; if it is set to 60Hz, the generator frequency should be
57Hz-63Hz.
10.2 DC Input (2
nd
Charging Port: CP2)
(Charging via Generator)
Pin1:DC1 PV+
Pin2:DC2 PV+
Pin3:DC1 PV-
Pin4:DC2 PV-
Pin2Pin1Pin3Pin4
Pin1:DC1 PV+
Pin2:DC2 PV+
Pin3:DC1 PV-
Pin4:DC2 PV-
Pin2Pin1Pin3Pin4
32
JUST POWER ON
