( Easy steps to solar charging )
10.2.1 Charging Method 3: Solar Charging (via 4pin aviation-MC4 cable)
•
How to connect EP500Pro to regular solar panel
EP500Pro supports dual PV input, DC1+DC2. Please make sure your solar panelsat
each input comply with:
Voc2: 12-150V Current: 12A Max. Power: 1200W Max.
a. Set “PV” as the “DC Input Source” .
b. Set “PV Parallel Enable” to “OFF”
c. Connect solar panels in series (Figure 1).
d. Connect the solar panels to EP500Pro via the DC charging cable (Figure 2, 3 ,4).
Note: Roof/Rigid panel can charge EP500Pro. If the panel's open circuit voltage falls
in 150-550V, use D300S to lower the voltage.
33
