© Julius Blum GmbH
3
110° CLIP top BLUMOTION hinge
Opening Angle Stop for 110° CLIP top BLUMOTION hinges,
86° restricted opening – 70T3553
•Remove
hinge from
mounting
plate
•Flip hinge
arm up to
closing
position
