© Julius Blum GmbH
4
110° CLIP top BLUMOTION hinge
Opening Angle Stop for 110° CLIP top BLUMOTION hinges,
86° restricted opening – 70T3553
•Install stop so
that the hooks
lock over
linkage pins
•Flip hinge
arm down to
opening
position
•Install hinge back onto
mounting plate
