AVENTOS HF Stops
 Opening Angle Stop for HF Aventos, 83° restricted opening – 20F7011
 Opening Angle Stop for HF Aventos, 104° restricted opening – 20F7051
Place the opening angle stop into the main
slot and locate the 2 notches on the underside
of the stop into the small cutouts.
Slide the opening angle stop in the main
slot upwards away from the arm until the
stop locks into position.
