BLUM TC52 User Manual

Mountingandcommissioning
©byBlum‐Novotest
19
V2A|04/2018
4.4 Mounting/changingofthestylus
TC50,TC51,TC52:
NOTICE
Damagetothemeasuringsystembyimpropermountingpossible.
 Themeasuringelementmaynotbedeflectedduringmounting.
 Whenmountingpleasealwaysusetheprovidedtools.
TC53‐10,TC53‐30,TC54‐10:
NOTICE
Damagetothemeasuringsystembyimpropermountingpossible.
 Themeasuringelementmaynotbedeflectedduringmounting.
 Whenmountingpleasealwaysusetheinterlockingdisk.
 Theinterlockingdiskmustfitbacklashfree.
 Pleaseensurethecorrectorientationoftheinterlockingdisk(inscriptionfacingupwards).
 Removetheinterlockingdiskbeforemeasurement.
 Damagedpartsarenotreusable!
Calibratethemeasuringsystemaftermountingbythecalibrationcycle.
