4.7 Programmingofthebasicadjustments
Inthismodethebasicadjustmentscanbechanged.
 Magneticpin
1. Removethebatteries.
2. Reinsertthebatteriesafter30sec.Pleasepayattentiontothepolarityofthebatteries.In‐
sertthebatterycompartmentlid.
TheLEDStatus(7)startsflashing.Thebasicadjustmentsaredisplayed(displayphase).
3. Switchtotheprogrammingmodeduringthedisplayphase:
HoldthemagneticpinonMODE,unti
lth
eLEDstatuschangesfromgreentoviolet.
4. Changeadjustments(SET):
HoldthemagneticpinonlabelSET.
5. Menuchange(MODE):
HoldthemagneticpinonlabelMODE.TheLEDStatusflashesbriefly,confirmingthemenu
change.
(7) LEDStatus
6. Afterthelastmenu,thebasicadjustmentswillberepeated(3xMODE‐SET).Duri
ngth
e
displayphase,itcanbechangedbackintotheprogrammingmode.
