BLUM TC54-10 User Manual

Systemoverview
V2A|04/2018
10
©byBlum‐Novotest
Tab.3‐3
TC52 TC53‐10
TC76‐T
TC54‐10
Approachdirection ±X,±Y,‐Z ±X,±Y, ±Z
a
a
seechapter4.5
±X,±Y, ±Z
a
Measuringforce
•directionX/Y: seeTab.3‐5...Tab.3‐7
Measuringforce
•directionZ: 5,7 N
1.6 N
10 N(TC52T)
5,9 N
2.0 N
5,9 N
2.0 N
10.6 N
(TC54‐10)
Max.deflection
•directionX/Y(seeTab.3‐4):
± 11°
±9°(TC52T) 15° ± 15°
•directionZ: 6mm
3.5 mm(TC52T)
5mm 5mm
Max.acceleration 50 m/s
2
200 m/s
2
(TC52T)
50 m/s
2b
b
withaccessories(e.g.extension,angle):max.acceleration10m/s
2
50 m/s
2
200 m/s
2

(TC54‐10T)
Repeatability
c
c
StylusL=30mm
0.3 µm 2σ
(Standard)
Z:0.2 µm 2σ(LF)
XY:0.3 µm 2σ(LF)
0.4 µm 2σ 0.4 µm 2σ
Max.probingspeed 2 m/min 2 m/min 2 m/min
Mass 250 g 225 g
(TC53‐10)
230 g
Protectionclass IP68
Signaltransmission Infrare d
Transmitterrange ±60°inZ,360°inX/Y
Battery(2pieces) SaftLithiumLS14250 (½ AA, 3.6 V) 1200 mAh
ToolholderHSK‐SK‐BT BTH25
Storagetemperature ‐20 °C ... +70 °C
Oper atingtemperature +5°C...+50°C
