Mountingandcommissioning
©byBlum‐Novotest
13
V2A|04/2018
4. Mountingandcommissioning
NOTICE
Damagescausedbyimproperinstallation/dismounting
 Useoriginalreplacementpartsonlyaswellastheprovidedspecialtools.
 Payattentiontothecorrectorientationoftheinterlockingdisk(inscriptionpointingtothe
stylus).
 Considerthemaximumtighteningtorque.
4.1 Insert/changebattery
TC50,TC51,TC53‐30
RecommendedbatteryType:
Tab.4‐1
Furtherrecommendations:
Tab.4‐2
TC52,TC53‐10,TC54‐10
RecommendedbatteryType:
Tab.4‐3
Type SaftLithiumLS14500(AA, 3.6 V)
mAh 2600
Contin.operation approx.254h
5%Use approx.20 7da ys
Standby approx.2years
Ordernumber 170407
TypeAA3.6V mAh
XenoXL‐060F 2400
V itzrocellSB‐AA11 2500
TadiranSL‐360 2400
Type SaftLithiumLS14250(½ AA, 3.6 V)
mAh 1200
Contin.operation approx.169h
5%Use approx.138days
Standby approx.2years
Ordernumber 170406
