4.6 Displayofthebasicadjustments
Themeasuringsystemcanbeconfiguratedfordifferentapplications.Afterthebatterieshave
beeninserted,thedisplayofthebasicadjustmentsisstarted.Themagneticpinisnotrequired.
1. Removethebatteries.
2. Insertthebatteriesafter30 sec.Observethepolarity ofthebatteries.Insertthe battery
compartmentlid.
TheLEDstatus(7)startstofla
sh.Theba
sicadjustmentsaredisplayed(displayphase).
3. Aftercompletingthedisplaythemeasuringsystemgoesintostandby.
Fig.4‐7
30 sec.
MODE SET
MODE
7
(7) LEDStatus
IftheLEDStatus(7)isflashingorshiningred,pleasecheckthebatteries,seechapter7.
Thebasicadjustmentscanbespecifiedonorder.
