System overview
 by Blum-Novotest 2012 13
Measuring force X/Y - T (robust design for lathes applications):
Stylus
length
(mm)
Measuring force X/Y - T (N)
TC62 T TC63-10/TC76-TT
TC63-30/TC76-TT
TC64-10 T
30 4,1 2,3
50 2,7 1,6
75 1,9 1,15
100 1,5 0,9
Tab. 2.7
Measuring force X/Y - LF (Low Force):
Stylus
length
(mm)
Measuring force X/Y - LF (N)
TC62 LF TC63-10/TC76-LF
TC63-30/TC76-LF
TC64-10 LF
30 0,65 0,4
50 0,44 0,3
75 0,31 0,2
100 0,24 0,17
Tab. 2.8
