System overview
10  by Blum-Novotest 2012
2.4 Technical data
TC60 TC61 TC63-30 / TC76-T
Approach direction
± X, ±Y, -Z XY*, -Z, +Z
± X, ±Y, ±Z
a)
Measuring force XY-direction
see Tab. 2.6 - Tab. 2.8
Measuring force Z-direction
7 N 4 N 5,9 N/2,0 N (LF)
Max. deflection XY
see Tab. 2.5
± 15° ± 15° * ± 15°
Max. deflection Z 10 mm -Z: 6 mm
+Z: 3 mm
5 mm
Max. acceleration
50 m/s
2
100 m/s
2
50 m/s
2 b)
Repeatability **
0,3 µm 2σ
0,3 µm 2σ
0,4 µm 2σ
Max. probing speed
3 m/min
5 m/min
2 m/min
Mass
925 g
920 g
790 g
Protection class
IP 68
Signal transmission
Radio
Frequency band 2,4000 – 2,4835 GHz
Transmission power
0 dBm
Operating range
15 m
Battery life
Saft Lithium LS 14500 (AA 3,6V)
Tool holder HSK–SK-BT
BTH 50
Operating temperature
+5 °C ... +50 °C
Storage temperature
-20 °C ... +70 °C
* via spindle orientation
** Stylus L=50 mm
a)
see chap. 3.5
b)
with accessories (e.g. extension, angle): max. acceleration 10 m/s
2
Tab. 2.3
