Package Contents
• 1 x SM11
• 1 x 5V / 1A DC power supply
• 1 x Mounting kit
• 1 x User manual
Maintenance
Clean this unit with a so, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.
Components inside this unit are not user serviceable. Do not remove the protective cover from the unit. Removing
any panel from this product will invalidate the manufacturers warranty.
Specifications
• Audio input connector: 1x analogue le/right audio (3.5mm stereo jack)
• Audio output connectors: 1x RCA (SPDIF) & 1x analogue le/right audio (3.5mm stereo jack)
• Video input connector: 1x HDMI Type A, 19-pin, female
• Video output connector: 1x HDMI Type A, 19-pin, female
• Mounting kit included
• Dimensions excl. connections (W x D x H ): 105mm x 87mm x 23mm
• Shipping weight: 0.5 kg
• Power: 5V / 1A DC, screw type connector
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Storage Temperature: -4°F to 140°F (-20°C to 60°C)
