SWAYCONTROL SELF DIAGNOSTICS
The SwayControl performs a self-diagnostic test every time it “wakes-up” upon
receiving a signal from the brake controller in the tow vehicle. The Status Light
may flash RED and GREEN approximately six times on start-up then go GREEN.
Once in operation, the SwayControl continually monitors the system for faults.
If the system is operating properly and no fault is detected, the GREEN light will
remain on and flicker or pulse.
If the SwayControl detects a fault in the system, the Status Light will turn RED
and the fault may be diagnosed from the RED Status Light flash sequence. The
SwayControl continues checking the fault status and the RED Status Light will
continue to flash until the fault is corrected. Once the fault has been corrected,
the GREEN light returns.
For more information, refer to Status Light LED Indicators.
STATUS LIGHT MODULE INSTALLATION
Once wiring is completed, route the Status Light cable to the front of the
caravan/trailer. Then mount the Status Light module onto a flat surface on the
drawbar of the caravan/trailer using self-tapping screws.
Select a location that makes it easy to see the Status Light when looking at the
front of the caravan/trailer.
WARNING
When the caravan/trailer is not moving, every 60 seconds the GREEN light will turn
off for two seconds, then turn back on. This is normal and indicates normal operation
of the SwayControl.
If you notice the GREEN light turning off and on every 60 seconds and the caravan/
trailer is moving, have your SwayControl checked by your local service centre.
