SWAYCONTROL WIRING HARNESS
The SwayControl wire harness has five wires requiring electrical connection and
one cable for the status LED light.
When making connections to the caravan/trailer’s wiring harness, the
desired termination is a solder joint. If the connection is not soldered, use
the appropriate size and type of “crimp-type” weather sealed heat-shrink
connectors, using the manufacturer’s recommended crimping tools in
accordance with their crimping instructions.
WIRING INSTRUCTIONS
WIRE TRAILER WIRE FUNCTION
MINIMUM WIRE
SIZE
PURPLE Left side electric brake output (all left side brakes) 1.8mm
PINK
Right side electric brake output (all right side
brakes)
1.8mm
WHITE Trailer battery/frame ground point 1.8mm
BLUE Electric brake controller signal from tow vehicle 1.8mm
BLACK
12V DC from tow vehicle trailer battery or BRK+
output. 30A fuse required
1.8mm
