BMPRO SwayControl User Manual

15
STATUS LIGHT LED INDICATORS
SEQUENCE CONDITION OR FAULT SOLUTION
Solid GREEN
pulsing
Normal operation
GREEN flash 5
times per second
SwayControl braking is active
1 GREEN flash
every 4 seconds
Module reset to manufacturer
default values. Keep trailer
still for 60 seconds (minimum)
before driving
If module does not return to normal
solid GREEN pulsing light after
3 system restarts, have the unit
checked at a service centre.
Continuous RED,
GREEN flash
Driving on rough terrain
and sway control of trailer is
disabled
Unit will return to normal operation
(GREEN light) when not on rough
terrain
No Light Unit in “sleep” mode
Activate manual override on the
brake controller to “wake-up” unit
No Light
No power after “wake-up” from
brake controller
Check quality of power, ground and
brake controller wire connections
Check for any blown fuses on the
tow vehicle and trailer
No Light
Over voltage, greater than 20V
detected
Check power source voltage,
correct voltage is 12-15V
No Light
Low voltage, less than 3V
detected
Check power source voltage,
correct voltage is 12-15V
Check quality of power and ground
connections
Solid RED System malfunction A service centre repair is required
1 RED flash System malfunction A service centre repair is required
2 RED flashes
Sensor malfunction - no sway
control of trailer
A service centre repair is required
3 RED flashes Left side brake short
Correct the short in left side brake
wiring
4 RED flashes Right side brake short
Correct the short in right side brake
wiring
Fast RED flashing Low voltage, between 3 and 6V
Check quality of power and ground
connections
If a service centre repair is required, please contact your BMPRO SwayControl
Authorised Repair Centre.
