BMS HELI-CODER 4 - Figure 6 CT-A-MP HC4 Mounting Plate - Dimensioned Drawing

Heli-Coder 4 Transmitter Operation Manual | Doc. No. 6051452100 Rev. C
Broadcast Microwave Services, Inc. 10
Figure 6 CT-A-MP HC4 Mounting Plate - Dimensioned Drawing
9.09"
(23.1 cm)
3.94"
(10.0 cm)
M6 Threaded
Hole (4 plcs)
1.85"
(4.71 cm)
1.79"
(4.55 cm)
11.18"
(28.4 cm)
5.12"
(13 cm)
0.98" (2.5 cm)
