4/201101 29 2 210 822© BMW AG, Munich (Z/Z) 4
Legend
A Wiring harness
B Bluetooth aerial
C Hands-free microphone (E90, E91, E92 cars only)
D Combox (not supplied with the retrofit kit)
E Combox holder (not supplied with the retrofit kit)
F Hands-free microphone finisher (2 x, dependent on colour, for cars without roof function centre only)
G Oval-headed screw (ST4, 2 x 13 mm)
H Hexagon screw (M5x20mm, 4x)
I Hexagon nut (M5, 4 x)
J SW 4-pin socket casing
K Adhesive strips (80 x 15 mm)
L Cable tie (10 x)
M Template (for cars without roof function centre only)
N Bluetooth aerial connecting cable
O Hands-free microphone (E93 cars only, not supplied with the retrofit kit)
P Adapter cable (E93 cars only)
Q Installation frame (E90, E91, E92 cars only)
R Steering column shroud (E93 cars only, not supplied with the retrofit kit)
S Cover cap
T 26-pin socket casing
U USB cable (to be given to the customer)
