Coolant
Checking coolant level
Make sure ground is level and
firm and park motorcycle.
Check coolant level on scale 1
of coolant reservoir.
Coolant level
between MIN and MAX
marks on the expansion tank
If coolant level is too low:
Add coolant.
Topping up coolant
Removing battery compartment
cover ( 113)
Remove screws 1 of right mir-
ror.
Remove mirror.
Remove two screws 1.
Remove short screw 2.
Remove three screws 3.
8
93
z
Maintenance
