F48�General�Vehicle�Electronics
5.�Heating/Air�Conditioning�Systems
46
5.1.2.�Heating�and�air-conditioning�unit
F48�Heating�and�air-conditioning�unit
Index Explanation
1 Air�vent,�top
2 Temperature�sensor,�center�vent
3 Temperature�sensor,�footwell�air�outlet
4 Heat�exchanger
5 Discharge�of�condensation�from�the�heating�and�air-conditioning�unit
6 Stepper�motor�for�blending�flap
7 Connector�at�the�control�unit�for�integrated�heating�/�air-conditioning
regulation/IHKA
8 Sleeve,�bulkhead
9 Blower�motor
10 Blower�output�stage
