F48�General�Vehicle�Electronics
5.�Heating/Air�Conditioning�Systems
47
F48�Heating�and�air-conditioning�unit
Index Explanation
1 Temperature�sensor,�center�vent
2 Stepper�motor�for�footwell�air�outlet,�left�and�right
3 Stepper�motor�for�defrost�function
4 Recirculated�air�flap
5 Ambient�air�intake�area�at�the�bulkhead
6 Stepper�motor�for�recirculated�air�flap�(with�kinematics�control)
7 Service�flap�of�two�microfilters
8 Stepper�motor�for�blending�flap
9 Evaporator�temperature�sensor
10 Ventilation�flaps,�air�vent�at�feet
11 Temperature�sensor,�footwell�air�outlet
12 Air�flaps,�center�vent
