Threaded fasteners
Front wheel Value Valid
Brake caliper to fork leg
M10 x 1.25 x 35 - 10.9 30 Nm
Clamp of quick-release axle
M8 x 30 Tighten screws six times in alternate
sequence
19 Nm
Quick-release axle in telescopic
forks
M24 x 1.5 50 Nm
Rear wheel Value Valid
Rear wheel to drive shaft
M10 x 1.25 x 40 tighten in a crosswise sequence
60 Nm
12
143
z
Technical data
