Final drive
Type of final drive Belt drive with jerk damping in its own housing
Frame
Frame type Aluminium composite bridge frame, engine also
load bearing
Type plate location Frame, front right, on steering head
Position of the Vehicle Identification Number Frame, front right, on steering head
Chassis and suspension
Front wheel
Type of front suspension Telescopic forks
Spring travel, front 125 mm, at wheel
Rear wheel
Type of rear suspension Single-arm light alloy cast swinging arm with rear
wheel axle adjustable via the eccentric
Type of rear suspension Central spring strut with coil spring, adjustable
rebound-stage damping and spring preload
Spring travel at rear wheel 123 mm, at wheel
12
147
z
Technical data
