Maintenance and care
2
Removing the front wheel
• Insert a suitable screwdriver
through hole A in quick-
release axle 8
• Pull out quick-release axle 8
to the right, turning it slightly
at the same time
• Remove bearing cap 9 and
spacing bushing 10
Mark the installed position on
the tire or ABS sensor ring or
note the direction-of-rotation
arrow if it is marked on the tire.
• Roll the front wheel forward
and out
When setting down the front
wheel, take care not to damage
the brake disks and the ABS
sensor ring.
Keep dirt and moisture away
from the wheel bearings.
8
9
A
10
