Maintenance and care
2
Installing the rear wheel
Use only wheel studs marked
with length code “55”.
Do not oil or grease.
Do not damage the brake disk,
wheel rim and ABS sensor ring
when installing.
• Check that the wheel center-
ing spigot and the contact
faces of wheel hub and spac-
ing washer 5 are free of
grease
• Roll the rear wheel into the
wheel arch from the rear
• Push spacing washer 5 onto
the wheel centering spigot
• Raise the rear wheel and
locate it on the swinging arm
• Insert rear wheel into center-
ing hole
5
