BMW k1200lt - Installing the Rear Brake

33
Maintenance and care
2
Installing the rear brake
Installing the brake caliper

Do not damage brake lines,
brake disk, brake pads or the
wheel when installing.
Do not damage the ABS sensor
cable, the ABS sensor ring and
the ABS sensor.
• Carefully slip brake caliper 3
over the brake disk

Make sure that bracket A for
the brake line is correctly
positioned.
3
A
