Technical Data
Wheel location
Front Telelever, leading link with central
spring strut, pivoted centrally on
main frame;
anti-dive fork bridge
Rear Cast aluminum single swinging
arm with reaction link to compen-
sate for shaft drive effects (Para-
lever); swinging arm with off-
center spring strut
Front suspension Gas-filled spring strut, no provi-
sion for adjustment
Spring travel (bump) 1.85 in (47 mm)
Spring travel (rebound) 2.17 in (55 mm)
Total travel 4.02 in (102 mm)
Fixed tube diameter 1.38 in (35 mm)
Rear suspension Gas-filled spring strut, hydraulic
spring preload steplessly adjust-
able by knob;
progressive damping
Spring travel (bump) 3.94 in (100 mm)
Spring travel (rebound) 1.18 in (30 mm)
Total travel 5.12 in (130 mm)
Swinging arm length 21.73 in (552 mm)
Frame and suspension
