139
Press locking mechanisms 1.
Loosen the diagnostic socket 2 from the
bracket 3.
The interface for the diagnosis and infor-
mation system can be connected to the
diagnostic socket 2.
Fastening the diagnostic socket
Disconnect the interface for the diagnosis
and information system.
Insert the diagnostic socket 2 into the
bracket 3.
The locks 1 engage.
Installing side trim panel ( 121).
